VETRON 5390 // 5391 // 5392
Direct-drive 1-needle lockstitch high post bed sewing machine with triple transport
Illustrtion VETRON 5392
"Special post bed sewing machine with extremely high post for the
application area of 3D processing"
The 5390 // 5391 // 5392 with VETRON technology is excellent for the processing of 3D and molded parts, due to the extremely large passage space of 350 x 570 mm and the high, slim post (430 mm). The narrow and short parts set is ideal for tight radiuses for the application areas automotive, shoes, bags, suitcases, etc.
VETRON 5390-18/01
Post left, electronically movable - for better insertion
of bulky material (for example suitcases). At pedal
start, the post moves automatically, stepper motor
controlled in the sewing position. Due to the stepper
motor controlled method of the post, the needle
distance to the hook can be adjustusted in the service
menu electronically.
5391-18/01
Post left - fixed
5392-18/01
Post right - fixed
Field of applications
Features & Technical data
5390 // 5391 // 5392
» Very high stitch quality for top-stitching work in the visible areas and for assembly seams
» Stitch type 301
» Horizontal hook (bobbin diameter 22 mm)
» Post height 430 mm
» 5390 post electronically movable to the left side for easy placing the material
» 5391 fixed post left side of needle
» 5392 fixed post right side of needle
» Large claerance under the machine arm (350 x 570 mm)
» Max. stitch length 6 mm
» Max. top-feed-stroke 9 mm
» Max. clearance under the sewing feet 20 mm
» Automatic top-feed-stroke adjustment
» Controlled needle thread tension
» Automatic adjustment of presser foot pressure
» Electric driven bobbin winder
» Electronic hand wheel
» Electronic back-tack lever
» Integrated LED sewing light
» No compressed air
* Depending on process
** Depending on version
High tech as standard
Through the consistent use of state of the art electronic control it became possible to make all machine settings programmable into memory and thus recallable.
This allows the process parameters to be free from operators influence and identical every time the program is recalled. The innovative dynamic machine parameter, based on the actual speed and the permanent measurement of the material thickness, open new possibilities of production quality, process security and the reduction of cycle times.
Control Panel P107
Simple operation - easy to remove
The control panel concept P107 is one of the new generations of control panels. It guarantees easy operation with simple navigation.
In the automotive production is this operating concept ideally suited for setting the sewing parameters and sewing programs / sequences. The control panel is simply removed after setting - the operator can no longer intervene in the sewing parameters.
More ease of use is impossible
Every operating element in the direct handle area
Electronic bobbin winder
Forward/backward selection key
Electronic hand wheel
Programmable button
Safety button
Forward/backward slider
Always fit to the application
Gauge part sets and accessories
As a supplement to the sewing machine series, VETRON also offers standard sewing accessories & tools.
In addition, the manufacture of special accessories is possible according to individual customer requirements.
